⚡ DUMEdb (Deterministic Unit-Record Memory Engine)

Hardware-aligned, zero-prompt-bloat, byte-structured memory engine, production Model Context Protocol (MCP) server, and drop-in OpenAI-compatible proxy gateway for autonomous AI agents.

🎬 Watch the Official Masterclass on YouTube:
Stop Force-Feeding Your AI 30,000 Tokens just to remind them who you are! — Featuring Frank, The Sentinel, and real-time live benchmarks.

🧭 Why DUMEdb?

Modern AI agents suffer from context rot, hallucination creep, and quadratic token bills when state is stuffed into raw conversation transcripts or retrieved fuzzily from high-dimensional vector databases.

Traditional Agent Memory (Context Stuffing):
[ System Prompt ] + [ 200 Turn Transcript Dump (85,000 tokens) ] + [ 10 Vector Chunks ] = 💥 Context Rot & High Cost

DUMEdb Memory Substrate:
[ System Prompt ] + [ Discrete 32-Byte Hardware Registers (220 tokens) ] + [ Active Turn ] = ⚡ 100% Deterministic & Instant

DUMEdb replaces conversational bloat with discrete, deterministic 32-byte binary registers stored in a memory-mapped database (LMDB). AI models read and mutate active state in microseconds with zero prompt bloat.

🔬 Binary Anatomy: The 32-Byte Unit Record

At the hardware core of DUMEdb is the Unit Record—a strictly aligned, 32-byte C-struct packed without pointer indirection:

 0                   1                   2                   3
 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|                                                               |
|                  ENTITY_ID (128-bit UUID)                     |
|                                                               |
|                                                               |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|          OPCODE (uint16)      |         FLAGS (uint16)        |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|                     TIMESTAMP (uint32 Unix)                   |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|                                                               |
|                    VALUE / PAYLOAD (64-bit)                   |
|                                                               |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+

• Entity UUID (16 bytes): Content-addressed or namespace-isolated actor/agent identity.
• Opcode (2 bytes): Schema-mapped semantic key (1001-65534).
• Flags (2 bytes): Bitfield indicating Active state, Float encoding, or Extension Payload pointer.
• Timestamp (4 bytes): Monotonic 32-bit second timestamp.
• Value (8 bytes): Inline immediate data (64-bit Int, IEEE-754 Float, Enum index, or SHA-256 payload hash reference).

⚡ Core Subsystems

1. 🔌 Model Context Protocol (MCP) Server (dume.mcp_server)

Full compliance with Anthropic's Model Context Protocol (MCP) specification over standard I/O (stdio):

• 15 First-Class MCP Tools: Provides direct tools for state reading (dume_read_state), transactional register mutation (dume_commit_state), filtered queries (dume_query), and dynamic schema cataloging (dume_list_schemas).
• Autonomous Session Orientation: Full Cabinet integration (cabinet_wake, cabinet_refresh) enabling zero-turn workspace context hydration.
• Plug-and-Play IDE Compatibility: Plugs directly into Claude Desktop, Cursor, Antigravity, Windsurf, and Cline with zero external network dependencies.
• Self-Healing Background Daemon: Automatically ensures local memory substrates and HTTP inspectors are active whenever the MCP harness starts.

2. 📁 Recursive Directory Ingestion Engine

Ingest entire software repositories, project documentation, or knowledge folders into deterministic state registers with a single call:

• Recursive Directory Crawler: Discovers and digests file trees while pruning noise (.git, node_modules, .venv, binaries).
• SHA-256 Content Deduplication: Identical files across locations are deduplicated in memory.
• Automatic Opcode Minting: Novel fields and parameters automatically mint clean, schema-typed opcodes in the 2001-65534 space.
• Atomic Single-Transaction LMDB Commits: Thousands of registers are persisted in milliseconds.

2. 🔄 OpenAI Universal Proxy Gateway (/v1)

Drop-in compatibility with any AI client: Cursor, Claude Desktop, VS Code (Cline), OpenWebUI, LangChain, or raw cURL.

• Intercepts requests pointing to http://localhost:8095/v1.
• Injects deterministic state registers ([DUME_STATE ...]) into the active prompt prefix with microsecond speed.
• Passes streaming completions transparently to upstream models (Ollama, vLLM, Groq, OpenAI, Anthropic).
• Automatically scribes assistant mutations in the background.

3. 🎛️ Dual-View Web Inspector

A visual cockpit for inspecting and managing agent memory in real time:

• Dual View: Switch between interactive cards and raw hardware hex dumps.
• Real-Time WebSocket Sync: Live updates as agents commit mutations.
• Directory Ingestion Modal: Instant folder crawling with one click.
• Token Telemetry & KV-Cache Runway: Real-time context monitoring.

4. 🗄️ The Cabinet

Autonomous session orientation ledger that maintains agent continuity across restarts, compacting work logs and next moves to eliminate "catch-me-up" context waste.

🚀 Quick Start (60 Seconds)

1. Installation

# Clone repository
git clone https://github.com/madbradsmith/DUMEdb.git
cd DUMEdb

# Install editable package
pip install -e .

2. Start the Engine & Inspector

# Start server (default port: 8095)
python -m dume --port 8095

# Or on Windows:
Start_DUMEdb_UI.bat

# Or on macOS/Linux:
./start_dumedb.sh

Console Output:

=======================================================
🚀 DUMEdb Studio v1.1.0 is Live!
🔗 Web Inspector: http://localhost:8095/inspector/index.html
⚡ Proxy Gateway: http://localhost:8095/v1
=======================================================

Open your browser to: http://localhost:8095/inspector/index.html

🔌 Connecting to Your Agent Tools

1. Model Context Protocol (MCP) — Claude Desktop, Cursor, Antigravity

DUMEdb is a native MCP server exposing deterministic memory tools over stdio. Add it to your client configuration:

Claude Desktop (claude_desktop_config.json) or Cursor (~/.cursor/mcp.json):

{
  "mcpServers": {
    "dumedb": {
      "command": "python",
      "args": ["-m", "dume.mcp_server"],
      "env": {
        "PYTHONUNBUFFERED": "1"
      }
    }
  }
}

Or via Docker:

{
  "mcpServers": {
    "dumedb": {
      "command": "docker",
      "args": ["run", "-i", "--rm", "madbradsmith/dumedb"]
    }
  }
}

Key MCP Tools Included:

• dume_read_state: Reads active registers for an entity directly from LMDB with zero prompt bloat.
• dume_commit_state: Transactionally writes 32-byte unit-record registers.
• dume_query: Queries memory registers with opcode and entity filtering.
• cabinet_wake: Zero-turn workspace orientation and memory retrieval.
• cabinet_refresh: Flushes session progress and odometers to disk for the next agent instance.

2. OpenAI Proxy Gateway — Cursor / VS Code (Cline / Continue)

Point your model base URL to the DUMEdb local proxy gateway:

{
  "openai.baseUrl": "http://localhost:8095/v1",
  "openai.apiKey": "dume-local"
}

Python SDK / OpenAI Client

from openai import OpenAI

client = OpenAI(
    base_url="http://localhost:8095/v1",
    api_key="dume-local"
)

response = client.chat.completions.create(
    model="llama3",
    messages=[
        {"role": "user", "content": "What is our current project status?"}
    ],
    extra_headers={"X-Entity-ID": "MadBrad-Nostra-01"}
)

print(response.choices[0].message.content)

Ingest a Directory via CLI / cURL

# Via cURL
curl -X POST http://localhost:8095/dume/ingest/directory \
  -H "Content-Type: application/json" \
  -H "X-Entity-ID: Project-Alpha" \
  -d '{"directory_path": "C:/Projects/MyAwesomeRepo", "recursive": true}'

# Via Python
from dume.intake.directory_reducer import DirectoryReducer

result = DirectoryReducer.reduce_directory("C:/Projects/MyAwesomeRepo")
print(f"Ingested {result['files_ingested']} files into {result['total_registers_extracted']} registers in {result['duration_ms']}ms.")

📐 Architecture Overview

                         ┌────────────────────────────────────────┐
                         │   Autonomous Agent / IDE / Chat UI     │
                         │   (Cursor, Claude Desktop, LangChain)  │
                         └───────────────────┬────────────────────┘
                                             │  OpenAI-Compatible
                                             ▼  HTTP /v1
                         ┌────────────────────────────────────────┐
                         │         DUME Universal Proxy           │
                         │  - Header entity resolution            │
                         │  - Context prefix assembly (<0.8μs)    │
                         │  - Inline directive parser (!set)      │
                         └───────┬────────────────────────┬───────┘
                                 │                        │
               Read/Write Mmap   │                        │ Async Pipeline
                                 ▼                        ▼
     ┌────────────────────────────────────┐    ┌─────────────────────────┐
     │      LMDB Memory Substrate         │    │   Scribe Worker Queue   │
     │  - 32-Byte Unit Records            │    │  - Mutation validation  │
     │  - Multi-version concurrency (MVCC)│    │  - WebSocket broadcast  │
     │  - Zero-copy binary struct unpack  │    └────────────┬────────────┘
     └────────────────────────────────────┘                 │
                                 ▲                          ▼
                                 │              ┌────────────────────────┐
                                 └──────────────┤  Dynamic Schema Dict   │
                                                │  - 65k Opcode Manager  │
                                                │  - JSON Disk Catalog   │
                                                └────────────────────────┘

🧪 Testing

DUMEdb includes a comprehensive pytest suite covering the core memory engine, LMDB concurrency, schema dictionaries, directory ingestion, and the OpenAI proxy substrate:

pytest tests/

☕ Support & GitHub Sponsors

If DUMEdb has saved your AI agents from context rot, slashed your API token bills, or improved your autonomous workflows, please consider supporting the project:

• ❤️ Sponsor MadBrad on GitHub
• ⭐ Star this repository to help other engineers discover deterministic memory
• 🗣️ Share the Masterclass with teams building production agent architectures

💼 Custom Features & Enterprise Deployments

Need DUMEdb tailored for a specialized agent framework, private cloud, or enterprise pipeline?

MadBrad is available for hire on a consulting / fee basis for:

• Custom Agent Substrates: Custom MCP servers, IDE integrations (Cursor, Claude Code, Windsurf, Antigravity), or tailored schema mappings for your proprietary data.
• Enterprise Deployments: Hardened on-premise LMDB memory clusters, automated multi-agent synchronization, and deterministic hydration bridges.
• High-Throughput Optimizations: Sub-microsecond binary state architectures for demanding production workloads.

To inquire about custom feature development or enterprise support, reach out via GitHub Sponsors or open a discussion thread on the repository.

📄 License

DUMEdb is licensed under the MIT License. Built for high-performance deterministic agentic computing.
